Drawbar Trailer

A drawbar trailer for sale is built differently from a semi-trailer: the axles carry the entire deck weight, so the towing truck only supplies pulling power and a small drawbar load instead of a fifth-wheel load. SIGMA supplies the 3 axle drawbar trailer as the standard configuration for 30-ton loads, and the 4 axle drawbar trailer for operators running heavier general cargo or machinery at 40 tons. Deck lengths run from a compact 6m drawbar trailer for tight yard work up to 13.5m for long freight, all on a full trailer chassis built for repeated coupling and uncoupling in road-train service.

What Sets a Drawbar Trailer Apart From a Semi-Trailer

A semi-trailer rests part of its weight on the towing tractor's fifth wheel. A drawbar trailer, also called a full trailer, carries its entire load on its own front and rear axle sets and connects to the towing truck through a drawbar rather than a kingpin. This means the truck pulling it can also carry a full body load of its own, since it isn't supporting any trailer weight. Fleets running a flatbed semi trailer for standard routes often add drawbar trailers to the same truck for higher-volume runs, forming a road-train combination without buying a second tractor unit.

3 Axle and 4 Axle Drawbar Trailer Configurations

SIGMA builds the drawbar trailer in 3-axle and 4-axle configurations depending on payload. Among 3 axle drawbar trailers for sale, this handles up to 30 tons and suits general freight and agricultural loads, while a 4 axle drawbar trailer for sale from the same range is rated to 40 tons for machinery, steel, and construction material. Both use a self-tracking front axle so the trailer follows the truck's turning path instead of cutting corners, which matters when a rigid truck and drawbar trailer combination is longer overall than a standard semi-trailer. Operators comparing capacity against a dry van trailer should note the drawbar trailer's open flatbed deck is built for crane and forklift loading rather than side or rear door access.

Deck Length Options From 6m to 13.5m

Deck length is one of the first specifications buyers narrow down, and demand splits between a compact 6m drawbar trailer for sale for yard and short-haul work and longer 9m to 13.5m decks for line-haul freight. The shorter deck suits operators moving palletized goods or machinery between nearby facilities, where a tight turning radius matters more than total length. Longer decks are better matched to timber, pipe, and structural steel that need continuous support along the load. Fleets running both configurations alongside an interlink trailer combination can standardize axles, brakes, and tires across the yard.

Chassis and Coupling Durability

Because a drawbar trailer is coupled and uncoupled far more often than a semi-trailer, the drawbar itself and its pivot bushings see more wear over the trailer's service life. SIGMA uses a reinforced Q345B steel drawbar with replaceable bushings and a pintle-hook or ring coupling matched to the customer's existing truck fleet. The flatbed deck is built on the same Q345B frame used across our flatbed trailer range, so timber decking, tie-down rails, and stake pockets can be specified the same way. Dual-line air brakes with ABS/EBS keep braking synchronized between the truck and trailer during road-train operation.
